Baguette MX Frameset - Öhlins
The Baguette MX frame kit with Öhlins TTX22M Air shock is the ideal solution for riders seeking an enduro bike ready to tackle anything. Designed for the most demanding terrains, this model combines the robustness and responsiveness of its Reynolds 853 steel frame with the unmatched performance of the Öhlins TTX22M Air shock, one of the best mountain bike shocks available.
The Öhlins TTX22M Air shock offers exceptional tuning precision for compression and rebound, allowing you to adapt the suspension to your specific needs, whatever the terrain. Thanks to its advanced technology, it ensures optimal shock absorption, providing a stable and comfortable ride even in the most challenging conditions.
The Baguette MX is designed with an optimal geometry for enduro, featuring a mullet setup (29" front and 27.5" rear) that strikes the perfect balance between stability and agility. Its 150 mm rear travel and 160 mm fork ensure smooth and responsive handling, even on the roughest trails.
This frame kit comes with all the essential components for a custom build: derailleur hanger, rear axle, derailleur dropout, headset, and frame hardware. This allows you to personalize your bike while benefiting from the top performance of a quality frame and a premium suspension.
Main features :
- Reynolds 853 steel frame, strong and responsive.
- Mullet format (29’’ front / 27.5’’ rear) for a perfect balance between stability and maneuverability.
- Progressive geometry, with a 64.8° head angle for precise and aggressive handling.
- 150 mm rear travel, designed to work with a 160 mm fork.
- Suspension : Öhlins TTX22M Air shock, for exceptional control and shock absorption.
- Compatible with tires up to 2.6" for maximum grip on all terrains.
- Included components : derailleur hanger, rear axle, derailleur dropout, headset, and frame hardware, shock.
Essential accessories for your Baguette frameset
Frame
Headset
Chain guide
Shock
Reynolds 853 multi butted steel
Deda ZS44-28.6 / EC44-40 black
FREESOLO™ V2-Top Slider Unit + Guide chaine Vario - DH (bottom slider and bash)
Öhlins TTX22M Air
Frame
Recommended fork length
Headtube
Headset
Max tire width (ETRTO)
Disc brake standard
Maximum diameter rear brake disc
Seatpost diameter
Bottom bracket
Front derailleur
Rear wheel axle
Max chainring size
Shock length / travel
Rear travel
Bushings sizes
Derailleur hanger compatibility
Frame bearings dimension
Reynolds 853 multi butted steel, high pivot, Glacier Cycles Smooth Attack Geometry (SAG)
576mm
44mm
ZS44-28.6 / EC44-40
66-622 front- 66-584 rear
PM 180
203mm
31.6mm
BSA 73mm
No
12x148mm
36 teeth
230x60mm
150mm
22x8mm - 30x8mm
Sram UDH
10/22/6mm (x6) - 16/28/7mm (x2)
